Customizable
Tailoring
Available
LINK-B Service Support Available
Support for CAN and RS Communication Protocols Available
Wireless Charging Solution Support Available
Specifications
01
Customizable
Tailoring Available
02
Support for CAN and RS
Communication
Protocols Available
03
LINK-B Service
Support Available
04
Wireless Charging Solution Support Available
Specifications
| Product Information | ||||||||
| 7S8P | 7S12P | 7S16P | 7S20P | 13S8P | 13S12P | 13S16P | 13S20P | |
| CELL | SAMSUNG SDI 50E | |||||||
| BMS | PCM 60A BMS 40A | PCM 80A BMS 80A | ||||||
| Communication support | PCM: No Support BMS: CAN 2.0A, RS485 Support | |||||||
| Size | 220×230×100mm | 209×336×100mm | 230×375×100mm | 280×375×100mm | 232×360×100mm | 326×360×100mm | 349×430×100mm | 349×524×100mm |
| Weight | 6.5kg | 9kg | 11.8kg | 14.3kg | 10.9kg | 15.8kg | 20.6kg | 25.2kg |
| Terminal Voltage | 17.5V | 17.5V | 17.5V | 17.5V | 32.5V | 32.5V | 32.5V | 32.5V |
| Nominal Voltage | 25.4V | 25.4V | 25.4V | 25.4V | 47.2V | 47.2V | 47.2V | 47.2V |
| Full Charge Voltage | 29.4V | 29.4V | 29.4V | 29.4V | 54.6V | 54.6V | 54.6V | 54.6V |
| Total Capacity | 39.2Ah | 58.8V | 78.4V | 98V | 39.2Ah | 58.8V | 78.4V | 98V |
| Rated Output | 996W | 1494W | 1991W | 2489W | 1850W | 2755W | 3700W | 4626W |
| Charging Mode | CC-CV Mode | |||||||
| Maximum Charging Current | PCM: ≤ 30A BMS: ≤ 20A | PCM: ≤ 30A BMS: ≤ 40A | ||||||
| Discharge Mode | CC Mode | |||||||
| Maximum Discharge Current | PCM: ≤ 60A BMS: ≤ 40A | PCM: ≤ 80A BMS: ≤ 80A | ||||||
| Operating Temperature | Charge °0C ~ 45°C Discharge -20°C ~ 60°C | |||||||
| Storage Temperature | Months -20°C ~ 60°C 6 Month -20°C ~ 45°C 1Year -20°C ~ 60°C | |||||||
